Polymaker PolyMide PA12-CF
Polymaker PolyMide PA12-CF
PolyMide PA12-CF is a carbon fiber reinforced PA12 (Nylon 12) filament. Thanks to PA12's low moisture sensitivity, this product has outstanding mechanical and thermal properties even after the moisture conditioning process. Combined with its easy printing with Warp-Free technology, this product is ideal for creating manufacturing tools.
- Excellent mechanical properties
- High heat resistance
- Carbon fiber reinforced
- Low sensitivity to moisture
Couldn't load pickup availability
Share


PolyMide
PolyMide is a family of nylon/polyamide based filaments. Produced using Polymaker's Warp-Free technology, PolyMide filaments provide the technical properties inherent in nylon and are easy to print.
PA12-CF
PolyMide™PA12-CF is a carbon fiber reinforced PA12 (Nylon 12) filament. Thanks to PA12's low moisture sensitivity, this product has outstanding mechanical and thermal properties even after the moisture conditioning process. Combined with its easy printing with Warp-Free™ technology, this product is ideal for creating manufacturing tools.
Recommended settings:
- Nozzle temperature: 260˚C - 300˚C *
- Print speed: 30mm/s - 60mm/s
- Bed temperature: 25 ˚C - 50 ˚C (DO NOT exceed 50 ˚C).
- Bed surface: Almost any surface with a thin layer of PVA glue or Magigoo PA.
- Cooling fan: OFF
- We strongly recommend using a durable nozzle
Technical Specifications
Basic Information |
|
Filament type |
PA |
Diameter |
2.85mm |
Weight |
0.50 kg |
Length |
74 m |
Paint |
Black |
|
|
Printing parameters |
|
Recommended minimum printing temperature |
260ºC |
Recommended maximum printing temperature |
300ºC |
Recommended min. bed temperature |
25ºC |
Recommended maximum bed temperature |
50ºC |
Recommendation My print speed |
30 mm/s |
Recommendation Max print speed |
60 mm/s |
Recommendation Min Fan Speed |
0% |
Recommendation Max fan speed |
0% |
Recommended Indentation Min |
3mm |
Generally |
|
Specific gravity |
1.06 g/cm3 ISO 1183 |
Temperature |
|
Heat deflection temperature |
105 °C ISO 75 |
Traction |
|
Tensile strength |
71.63 MPa ISO 527 |
Tensile modulus |
3304.39 MPa ISO 527 |
Bendability |
|
Bending strength |
109.97 MPa ISO 178 |
Flexural modulus |
3535 MPa ISO 178 |
Other |
|
Impact strength |
12.52 KJ/m2 ISO 179 |
